Advanced Gem Faceting Machine

High precision gem faceting and polishing machine for cutting your gemstones with near-perfect accuracy and ease. The machine comes equipped with a top-notch brushless DC (BLDC) motor rated 220 watts with a variable speed of up to 3000 RPM. So you can be assured of enough power even when cutting the hardest of stones. It’s a direct-drive system which means the grinding and polishing discs run extremely true with minimal noise. No belts and pulleys whatsoever.

You can mount up to 200 mm (8”) discs on the machine. It comes with an easy and responsive angle adjustment, index adjustment, and mast adjustment. The machine comes with 96 and 72 indexing gears, two 8” grinding discs, 8" Zinc polishing lap, Brass dopstick set with numerous shapes and sizes, a 45-degree angle adapter for convenient table polishing, a transfer jig, an indicator dial and four packs of 25ct Diamond Powder. So you are all covered in terms of accessories and supplies, to begin with.


Availability: In stock


  • The machine is powered by a direct-drive 220 watt brushless DC (BLDC) motor. BLDC motors are the highest-standard DC motors popular for their long life and precise speed control. The motor offers variable speeds up to 3000 RPM.
  • Accurate angle adjustment with a clear indicator and a precision of 1 decimal place.
  • Convenient and quick index adjustment. The design allows changing of index quickly with single-handed use. This makes faceting and polishing fast and convenient. The machine comes with a 96 indexing gear installed and a spare 72 indexing gear.
  • A cheater adjustment wheel is provided in the facetor for those fine adjustments to the index, sometimes necessary to produce perfect facets.
  • The base plate is an 8mm thick sturdy and finely ground industrial-grade fabricated Aluminium. So you can be assured the machine is mounted on a steady base.
  • Doping is fast and precise. The machine comes with a set of brass dop sticks that are keyed. Therefore, they are locked in the doping chuck in the exact position every time.
  • The indicator dial indicates whether the stone has been cut at the exact angle. The dial indicator reading will show a non-zero reading if the angle of cut on the stone is different from the machine’s angle. A zero reading indicates a perfect angled cut is achieved. This comes in quite handy especially if you are a beginner.
  • The mast can be loosened, moved, and tightened easily. Its ground finished so the faceting unit can be moved up and down smoothly. It is equipped with a fine height adjustment knob on top.
  • The machine is equipped with a drip water system with an adjustable hose and flow control.
  • The machine comes with a white light powerful LED lamp with an adjustable gooseneck.
  • Cutting & polishing the girdle is super easy on the machine. Also, the facetor comes with a setting for free rotation. This is very handy for making smooth round girdles.
  • Cutting & polishing the table of the stone can be easily done using a 45-degree adapter that comes with the machine. The adapter essentially reduces 45 degrees from the reading on the angle indicator of the machine. Therefore, to achieve a 0-degree angle (which is required to make the table), the machine can be set at 45 degrees while using the 45-degree adapter.
  • A water drainage outlet is provisioned on the side of the base. Water drains from the bottom of the splash guard to this outlet.



  • 1 Pc. 200mm (8") Zinc polishing lap.
  • 2 Pcs. 200mm (8") Diamond lap for grinding.
  • 4 Pcs. 25-carat diamond grit pack
  • 1 Pc. Aluminum master lap for backing the diamond lap.
  • 1 Pc. Brass dop stick set (with various shapes and sizes)
  • 1 Pc. 45-degree table adapter
  • 1 Pc. Dop transfer jig
  • 1 Pc. Drainage hose
  • 1 Pc. Dial indicator
  • 1 Pc. Led Lamp
  • 1 Pc. Superglue for doping
  • Toolkit


  • Length x Width x Height: 460 mm X 360 mm x 400 mm
  • Motor spindle speed: Variable (0-3000 rpm)
  • Motor power: 220 Watts
  • Lap diameter: 200 mm (8”)
  • Power supply:  AC 220 volts or AC 110 Volts
  • Net weight: 18 kg



  • It’s a feature-packed machine. It has almost everything you will ever need to make great faceted stones.
  • It comes with an unparalleled set of accessories included. So you won’t have to spend a single penny more to get you started and working for a long time.
  • It’s beginner-friendly. We let some amateur lapidary artists give this machine a try and the single biggest feedback we received is it’s the easiest and most convenient faceting machine they have ever used. A lot of them started pursuing the hobby again!
  • Making preforms, girdles, and tables on this machine is a breeze.
  • Despite the features and an unrivaled price point, we pledged to not cut any corners. We use the best-in-class BLDC motor, industrial-grade materials like aluminum, stainless steel, and precise machining techniques. Credit to our efficient team of engineers.



  • 1-year manufacturer warranty (Does not cover physical damage and consumables).
  • Installation and operation support.
  • Drop us an email at or contact us from the website for any assistance. We’d be quick to respond and glad to help.



  • For International customers, the fees on import duty or customs charges will not be incurred by us. Every country’s customs policies are different and must be considered by the customers on their own.
  • Our logistics partners are DHL & FedEx. If any of these have operations in your country, we should be able to ship the products to you.
  • The shipping of this faceting machine is insured.
  • Time for shipping varies depending on the shipping region but usually, it takes not more than 10 business days to be delivered anywhere in the world, once it’s dispatched. The dispatch times vary depending upon stock availability.


  • The machine is shipped in a sturdy honeycomb box.
